CLARK NPR17 Electric Narrow Aisle Forklift
Clark NPR electric narrow asile reach and straddle trucks are designed to meet the increasing performance and reliability demands of narrow aisle applications. Its easy operation with strong and reliable component systems provide high user value for operators. General Electric transistor motor controls operate drive and power steering/reach/tilt and auxiliary functions, which add significantly to battery efficiency, with benefits of fewer parts and built-in diagnostics.
Reach out to your local Westerra Equipment dealership to learn more about our wide range of CLARK material handling products.
Specifications
| Caster Wheel Size | 8 x 4 in |
| Brakes | Drum & Shoe |
| Lowered Overall Height | 89.0 in |
| Standard Mast: Free Lift | 54.0 in |
| Maximum Fork Height | 198.0 in |
| Mast | 3-Stage |
| Maximum 6 hour AH Capacity | 1240.0 Ah |
| Battery Compartment Size (L x W x H) | 38.8 x 13.9 x 32 in |
| Drive Motor | Single |
| Control Type | GE EV-T15 |
| Minimum Battery Weight | 1590.0 lbs |
| Plug Type | SB-350 Red |
| Voltage | 24.0 V |
| Steering | Power |
| Center of Wheelbase | 1.75 in |
| Maximum Fork Spread | 31.0 in |
| Overall Length | 70.25 in |
| Overall Width | 53.0 in |
| Wheelbase | 56.1 in |
| Height to Top Overhead Guard | 89.0 in |
| Fork Size (T x W x L) | 1.8 x 4 x 42 in |
| Load Wheel Size | 5 x 3.8 |
| Drive Tire Size | 13.5 x 5.5 |
| Load Center | 24.0 in |
| Lifting Speed (Loaded/Unloaded) | 0.7/1.1 ft/sec |
| Lowering Speed Loaded/Unloaded | 1.3/1.5 ft/sec |
| Travel Speed Loaded | 5.8 |
